HP 5800-48G-PoE Switch

Přidat do oblíbenýchHP 5800-48G-PoE Switch
Provedení:Rack mounted 19"; Technologie:Gigabit Ethernet 1000Mbps; Management:SNMP/RMON; Maximální počet portů:48; Vlastnosti switche:Fuknce POE po portech.

Kód produktu460213
Part numberJC104A
EAN produktu885631165904

Záruka:99 Doživotní
Výrobce:Hewlett Packard Enterprise
Skladová dostupnost:Na dotaz
Běžná cena
415730 Kč
Vaše cena bez DPH
251959.50 Kč
Vaše cena včetně DPH
304871 Kč
Počet
ks
Dotaz na prodejce >






Přidat produkt k porovnání >Přidat produkt k oblíbeným >
Popis
Parametry
Hlídací pes

HP A5800G switches offer an unmatched combination of Gigabit and 10-Gigabit Ethernet port density, high-availability architecture, and full Layer 2 and Layer 3 dual-stack IPv4 and IPv6 capabilities. Besides wire-speed line-rate performance on all ports, the switches include patented Intelligent Resilient Framework (IRF) technology and Rapid Ring Protection Protocol (RRPP) that allow local or geographically distributed A5800 switches to be interconnected for higher resiliency and performance. Available in PoE and non-PoE models and 1 RU and 2 RU flex chassis configurations, A5800 switches are built on open standards and include an open application architecture (OAA) module slot that that enables flexible deployment options for new services. These versatile switches are ideal for use in the network core for a building or department, or as a high-performance switch in the convergence layer or network edge of enterprise campus networks.


Ports
48 RJ-45 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T); Duplex: 10Base-T/100Base-TX: half or full; 1000Base-T: full only
1 extended module slot
4 SFP+ fixed 1000/10000 SFP+ ports
1 RJ-45 serial console port


Physical characteristics
Dimensions
16.81(d) x 17.32(w) x 1.72(h) in. (42.7 x 44.0 x 4.36 cm) (1U height)
Weight
18.74 lb. (8.5 kg)


Memory and processor
512 MB SDRAM, 512 MB flash; packet buffer size: 8 MB


Performance
Throughput
190 million pps
Routing/Switching capacity
256 Gbps
Routing table size
16,000 entries
MAC address table size
32,000 entries


Environment
Operating temperature
32°F to 113°F (0°C to 45°C)
Operating relative humidity
10% to 90%


Electrical characteristics
Maximum heat dissipation
447 BTU/hr (471.59 kJ/hr)
Voltage
100-120 / 200-240 VAC
Frequency
50 / 60 Hz


Safety
UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR Subchapter J; NOM; ROHS Compliance


Emissions
VCCI Class A; EN 55022 Class A; ICES-003 Class A; ANSI C63.4 2003; AS/NZS CISPR22 Class A; EN 61000-3-2:2006; EN 61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A


Immunity
Generic
ETSI EN 300 386 V1.3.3
EN
EN 55024:1998+ A1:2001 + A2:2003
ESD
EN 61000-4-2; IEC 61000-4-2
Radiated
EN 61000-4-3; IEC 61000-4-3
EFT/Burst
EN 61000-4-4; IEC 61000-4-4
Surge
EN 61000-4-5; IEC 61000-4-5
Conducted
EN 61000-4-6; IEC 61000-4-6
Power frequency magnetic field
IEC 61000-4-8; EN 61000-4-8
Voltage dips and interruptions
EN 61000-4-11; IEC 61000-4-11
Harmonics
EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3


Management
IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager; Telnet; HTTPS; RMON1; FTP


Services
3-year, 4-hour onsite, 13x5 coverage for hardware (UV882E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UV885E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (UV888E)
3-year, 24x7 SW phone support, software updates (UV891E)
Installation with minimum configuration, system-based pricing (UW451E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UV883E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UV886E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UV889E)
4-year, 24x7 SW phone support, software updates (UV892E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UV884E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UV887E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UV890E)
5-year, 24x7 SW phone support, software updates (UV893E)
3 Yr 6 hr Call-to-Repair Onsite (UW969E)
4 Yr 6 hr Call-to-Repair Onsite (UW970E)
5 Yr 6 hr Call-to-Repair Onsite (UW971E)


Refer to the HP website at: www.hp.com/networking/services for details on the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.


Standards and protocol (applies to all products in series)
General protocols
IEEE 802.1ag Service Layer OAM
IEEE 802.1D MAC Bridges
IEEE 802.1p Priority
IEEE 802.1Q VLANs
IEEE 802.1s (MSTP)
IEEE 802.1v VLAN classification by Protocol and
Port
IEEE 802.1w Rapid Reconfiguration of Spanning
Tree
IEEE 802.1X PAE
IEEE 802.3ad Link Aggregation Control Protocol
(LACP)
IEEE 802.3ae 10-Gigabit Ethernet
IEEE 802.3x Flow Control
RFC 768 UDP
RFC 792 ICMP
RFC 793 TCP
RFC 826 ARP
RFC 854 TELNET
RFC 925 Multi-LAN Address Resolution
RFC 951 BOOTP
RFC 1058 RIPv1
RFC 1350 TFTP Protocol (revision 2)
RFC 1519 CIDR
RFC 1542 BOOTP Extensions
RFC 2131 DHCP
RFC 2453 RIPv2
RFC 3046 DHCP Relay Agent Information Option
RFC 3576 Ext to RADIUS (CoA only)
RFC 3768 VRRP
RFC 4675 RADIUS VLAN & Priority
802.1r - GARP Proprietary Attribute Registration
Protocol (GPRP)


IP multicast
RFC 2934 Protocol Independent Multicast MIB for
IPv4
RFC 3376 IGMPv3 (host joins only)
RFC 3618 Multicast Source Discovery Protocol
(MSDP)
RFC 3973 Draft 2 PIM Dense Mode
RFC 4601 Draft 10 PIM Sparse Mode


IPv6
RFC 2080 RIPng for IPv6
RFC 2460 IPv6 Specification
RFC 2710 Multicast Listener Discovery (MLD) for
IPv6
RFC 2740 OSPFv3 for IPv6
RFC 2925 Remote Operations MIB (Ping only)
RFC 3019 MLDv1 MIB
RFC 3162 RADIUS and IPv6
RFC 3315 DHCPv6 (client and relay)
RFC 3315 DHCPv6 (client only)
RFC 3810 MLDv2 (host joins only)
RFC 4022 MIB for TCP
RFC 4251 SSHv6 Architecture
RFC 4252 SSHv6 Authentication
RFC 4253 SSHv6 Transport Layer
RFC 4254 SSHv6 Connection
RFC 4293 MIB for IP
RFC 4419 Key Exchange for SSH
RFC 4443 ICMPv6
RFC 4541 IGMP & MLD Snooping Switch
RFC 4861 IPv6 Neighbor Discovery
RFC 4862 IPv6 Stateless Address Auto-configuration
MIBs
IEEE 8021-PAE-MIB
IEEE 8023-LAG-MIB
RFC 1213 MIB II
RFC 1493 Bridge MIB
RFC 1657 BGP-4 MIB
RFC 1724 RIPv2 MIB
RFC 1850 OSPFv2 MIB
RFC 2011 SNMPv2 MIB for IP
RFC 2013 SNMPv2 MIB for UDP
RFC 2233 Interface MIB
RFC 2273 SNMP-NOTIFICATION-MIB
RFC 2452 IPV6-TCP-MIB
RFC 2454 IPV6-UDP-MIB
RFC 2465 IPv6 MIB
RFC 2466 ICMPv6 MIB
RFC 2571 SNMP Framework MIB
RFC 2572 SNMP-MPD MIB
RFC 2573 SNMP-Notification MIB
RFC 2618 RADIUS Client MIB
RFC 2620 RADIUS Accounting MIB
RFC 2665 Ethernet-Like-MIB
RFC 2674 802.1p and IEEE 802.1Q Bridge MIB
RFC 2688 MAU-MIB
RFC 2787 VRRP MIB
RFC 2819 RMON MIB
RFC 2925 Ping MIB
RFC 3414 SNMP-User based-SM MIB
RFC 3415 SNMP-View based-ACM MIB
RFC 3418 MIB for SNMPv3
RFC 3621 Power Ethernet MIB
RFC 3826 AES for SNMP's USM MIB
RFC 4133 Entity MIB (Version 3)
LLDP-EXT-DOT1-MIB
LLDP-EXT-DOT3-MIB
LLDP-MIB


Network management
IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
RFC 2819 Four groups of RMON: 1 (statistics), 2
(history), 3 (alarm) and 9 (events)
RFC 3176 sFlow
ANSI/TIA-1057 LLDP Media Endpoint Discovery
(LLDP-MED)
SNMPv1/v2c/v3


OSPF
RFC 2328 OSPFv2
RFC 3101 OSPF NSSA


Security
IEEE 802.1X Port Based Network Access Control
RFC 1492 TACACS+
RFC 2865 RADIUS (client only)
RFC 2866 RADIUS Accounting
Secure Sockets Layer (SSL)
SSHv2 Secure Shell


HP A5800 Switch Series

.
Maximální počet portů: 48
Technologie: Gigabit Ethernet 1000Mbps
Management: SNMP/RMON
Vlastnosti switche: Fuknce POE po portech
Provedení: Rack mounted 19"
